14×7 Heavy Duty Fully Welded Flat Top Tandem Trailer ATM 3500KG (Model No: SP47FTE)
Features
ATM 3.5T Rated
Free 8” Jockey Wheel
New Plug in Design Posts (Steady and Easy to Remove)
4 Tie Down Rails are Welded All The Way Around
Electric Brakes on 4 wheels
All Gates Can Be Easily Removed
Fully Welded Body
Reinforced Chassis & Hinges
Greasable Rocker Roller Suspension
Specifications
| ATM | 3500kg |
| Internal Size | 4250x2120mm |
| External Size | 6200x2250mm |
| Drawbar | 1800mm 100x50x4.0mm |
| Chassis Frame | 70x50x3.0mm |
| Finish | Hot Dipped Galvanised (Rust free) |
| Side | 300mm High Removable |
| Floor | 2.5mm 2 Piece of Fully Welded Checker Plate |
| Jockey Wheel | 8" Steel Rim Swing up |
| Tyre | Brand New 15" 195/R15LT Light Truck |
| Axle | 50x50mm Square Solid With 2 Tonne Bearing |
| Suspension | Heavy Duty Greasable Rocker Roller Suspension |
| Coupler | 50mm Australia Standard |
| Lights plug | Round or Flat 7 Pin Plug |
| Spring | Heavy Duty 8 Leaf Greasable Rocker Roller Suspension |
| Safety Chain | 13mm |
| Break | Electric Brakes on All 4 Wheels with Breakaway Unit |
| Light | LED Tail Lights & Clearance Lights |
