12×6 Heavy Duty Fully Welded Tandem ATM 3200KG (Model No: SP26TWE)
Features
ATM 3200KG
Chassis and Draw Bar Are Welded Together, Not Only Bolted.
Free 8” Jockey Wheel
New Plug in Design Cage (Steady and Easy to Remove)
4 Tie Down Rails are Welded All The Way Around
Front and Rear Tailgates That Can Be Easily Removed
Extended Foot Step for Jerry Can Hold and Toolboxes.
Fully Welded Body
Reinforced Chassis & Hinges
Greasable Rocker Roller Suspension
Specifications
| ATM | 3200kg |
| Internal Size | 3640x1820mm |
| External Size | 5680x2350mm |
| Drawbar | 1800mm 100x50x4.0mm |
| Chassis Frame | 70x50x3.0mm |
| Finish | Hot Dipped Galvanised (Rust free) |
| Side | 300mm High (One Piece of Checker Plate Fold Up, No Gap.) |
| Floor | 2.5mm 2 Piece of Fully Welded Checker Plate |
| Cage | 900mm |
| Jockey Wheel | 8" Steel Rim Swing up |
| Tyre | Brand New 15" 195/R15LT Light Truck |
| Axle | 50x50mm Square Solid |
| Suspension | Heavey Duty Greasable Rocker Roller Suspension |
| Coupling | 50mm Australia Standard |
| Lights plug | Round or Flat 7 Pin Plug |
| Spring | Heavy Duty 7 Leaf Eye to Eye Spring |
| Bearing | Heavy Duty Parallel Bearings |
| Safety Chain | 13mm |
| Break | Electric Brakes on All 4 Wheels with Breakaway Unit |
| Light | LED Tail Lights & Clearance Lights |
